RCH Series Single Acting Hollow Purpose Hydraulic Cylinder

RCH series cylinder is hollow plunger designed and it allows for both pull and push forces. WREN hydraulic cylinders are available in hundreds of different configurations. Whatever the industrial application, lifting, pushing, pulling, bending, holding, whatever the force capacity, stroke length or size restrictions, single- or double-acting, solid or hollow plunger you can be sure that WREN has the cylinder to suit your high force application.

RCH series cylinder is hollow plunger designed and it allows for both pull and push forces. WREN hydraulic cylinders are available in hundreds of different configurations. Whatever the industrial application, lifting, pushing, pulling, bending, holding, whatever the force capacity, stroke length or size restrictions, single- or double-acting, solid or hollow plunger you can be sure that WREN has the cylinder to suit your high force application.

Product Details

-Hollow plunger design allows for both pull and push forces

-Single-acting and heavy-duty return spring.

-Baked enamel finish for the improved corrosion resistance

-Hollow plunger design allows for both pull and push forces

-Single-acting and heavy-duty return spring.

-Baked enamel finish for the improved corrosion resistance

Model Capacity Stroke Min Height Outside Diameter Effective Area Oil Capacity Plunger Diameter Hollow Diameter Weight
ton mm mm mm cm² cm³ mm mm kg
RCH120 12 8 55 69.8 17.9 14 35 19.6 1.5
RCH121 12 42 121 69 17.9 75 35 19.6 2.8
RCH123 12 76 184 69 17.9 136 35 19 4.4
RCH202 20 51 163 99 30.5 152 55 28 7.7
RCH206 20 155 306 99 30.5 473 55 28 14.1
RCH302 30 64 179 115 47.7 305 63 34 10.9
RCH306 30 155 331 115 47 739 63 34 21.8
RCH603 60 77 248 160 84.2 648 92 53 28.1
RCH606 60 152 325 160 84.2 1280 92 53 35.4
RCH1003 100 76 255 212.7 135.3 1028 127 78 63
Model Capacity Stroke Min Height Outside Diameter Effective Area Oil Capacity Plunger Diameter Hollow Diameter Weight
ton mm mm mm cm² cm³ mm mm kg
RCH120 12 8 55 69.8 17.9 14 35 19.6 1.5
RCH121 12 42 121 69 17.9 75 35 19.6 2.8
RCH123 12 76 184 69 17.9 136 35 19 4.4
RCH202 20 51 163 99 30.5 152 55 28 7.7
RCH206 20 155 306 99 30.5 473 55 28 14.1
RCH302 30 64 179 115 47.7 305 63 34 10.9
RCH306 30 155 331 115 47 739 63 34 21.8
RCH603 60 77 248 160 84.2 648 92 53 28.1
RCH606 60 152 325 160 84.2 1280 92 53 35.4
RCH1003 100 76 255 212.7 135.3 1028 127 78 63
