H-WEDCX Series Recharagable Battery Torque Wrench

H-WEDCX

With a new torque display and buttons, this newly designed H-WEDCX battery torque wrench offers unmatched power, versatility and reliability. H-WEDCX Preferred Series allows users to choose the target torque more conveniently.

H-WEDCX

With a new torque display and buttons, this newly designed H-WEDCX battery torque wrench offers unmatched power, versatility and reliability. H-WEDCX Preferred Series allows users to choose the target torque more conveniently.

Product Details

· Digital torque setting, adjustable every 1 Nm.

· Torque up to 8000 Nm with automatic release of reaction arm as standard.

· For applications with limited power sources or field service.

· Longer battery life, two batteries and one charge are standard

· Digital torque setting, adjustable every 1 Nm.

· Torque up to 8000 Nm with automatic release of reaction arm as standard.

· For applications with limited power sources or field service.

· Longer battery life, two batteries and one charge are standard

Model Square drive Torque Rotating speed Weight Size(mm)
N.m rpm kg A B C D
H-WED07CX 3/4" 100~700 18 3.5 235 63 67 262
H-WED14CX 3/4" 300~1400 6 3.7 246 63 67 262
H-WED20CX 1" 400~2000 6 4 244 63 69 262
H-WED40CX 1" 800~4000 3.5 6 285 69 81 266
H-WED70CX 1.1/2" 1350~7000 2.4 8.8 295 95 95 272
H-WED80CX 1.1/2" 1500~8000 1.2 10 311 102 102 275



Model Square drive Torque Rotating speed Weight Size(mm)
N.m rpm kg A B C D
H-WED07CX 3/4" 100~700 18 3.5 235 63 67 262
H-WED14CX 3/4" 300~1400 6 3.7 246 63 67 262
H-WED20CX 1" 400~2000 6 4 244 63 69 262
H-WED40CX 1" 800~4000 3.5 6 285 69 81 266
H-WED70CX 1.1/2" 1350~7000 2.4 8.8 295 95 95 272
H-WED80CX 1.1/2" 1500~8000 1.2 10 311 102 102 275
